Size: 1/2"-3", DN10-DN65
Material: 316L/1.4404, ASME BPE 316L 1.4435 NB2 Fe≤0.5%
Pressure: vacuum to 10bar (1.0Mpa)
Seal: EPDM FKM PTFE
Connection way: threaded, clamp, welding, flange
Drive mode: manual, pneumatic, electric
Roughness: Ra≤0.6μm; MP=Ra≤0.3μm; EP=Ra≤0.3μm
Sanitary manual radial diaphragm valve
It has the characteristics of simple maintenance and installation, high efficiency, small size, light weight, low flow resistance and economy. There are more than 20 types of valve body combinations.
Certificates
All synthetic resin and additive are comply with FDA certification
Material chemical composition, physical properties and manufacturing process are documented
All diaphragm seal consistency with FDA certificate
-21-CFR-FDA 177.1550 perfluorocarbon synthetic resin
-21-CFR-FDA-177.2600 rubber
USP 28 class VI CHAPTER 87 IN VITON and CHAPTER 88 IN - VITON consistency the authentication
3 - A consistency the authentication NO.: 54-02-1580
EN 10204-3.1 Certificate on traceability of stainless steel Chemical composition synthesis
CE-PED/97/23/EC N.O.: TUV DGR 0036-QS-1153-14
Technical Features
●Temperature: -20℃ to +150℃, Depending on the seal material
●Connection standard: DIN SMS ISO IDF RJT BS4825 ASME BPE 3A DIN11864 DIN11853
●Certification: FDA 177.2600; 3A-18-03; Glass II USP Glass VI Chapter 88; GB4806.11; EG VO/1935-2004; PED/97/23/EC.
Sanitary Radial diaphragm valve drawing
| File | Language | Size |
|---|---|---|
 Radial diaphragm valve catalogue |
English | 14.83MB |
| Sanitary valve catalogue |
English | 30.2MB |
