In the modern industrial field, fluid control is a vital task. However, the problem of mixing between different fluids has been plaguing many companies. In order to solve this problem, the mixproof valve will become a powerful assistant for industrial safety and production efficiency.
The main advantage of the mixproof valve is that it can be cleaned and sterilized online in situ CIP. This technical feature allows the valve to be thoroughly cleaned and disinfected without disassembly. This not only greatly reduces maintenance costs and the risk of production interruption, but also ensures the sanitation and safety of the production environment, effectively preventing bacterial growth and cross-contamination.
The mixproof valve also has the technical characteristics of self-draining, no dead angle inside and no retention. When the valve is closed, it can automatically empty the residual fluid inside to avoid dead angle and retention. This not only effectively prevents fluid mixing, but also ensures the cleanliness and smoothness of the pipeline system, further improving production efficiency and product quality.
The mixproof valve also has very flexible configuration options. It can be combined with automatic control systems such as position feedback, valve control unit C-TOP, position sensor, etc. to achieve precise valve control and monitoring. This flexible configuration enables the mixproof valve to be customized according to different production needs and scenarios to better meet the actual needs of enterprises.
In practical applications, mixproof valves have been recognized and praised by a large number of users. Whether in food, dairy, medicine, chemical industry or other industries, it can play an excellent role and bring significant benefits to enterprises. Many companies said that the use of mixproof valves in the production process will effectively solve the problem of fluid mixing, and production efficiency and quality will be significantly improved.
Technical spefication
Size |
1.5”-6” DN40-DN150 |
Max pressure |
6 bar |
Mininum pressure |
Vacuum |
Working temperature |
-10℃ to 120℃(150℃ optional) |
Applicable medium |
Milk,beer,water,oil and other liquids |
Inlet and outlet connection way |
Clamp,welding,thread,flange |
Air pressure |
5-7 bar |
Air supply size |
G 1/4 |
Liquid detecting pressure |
6 bar |
Air detection pressure |
6 bar |
Material
Part |
Material/ Surface |
Wett contact part |
316L/1.4404 |
Other parts |
AISI 304/1.4301 |
Seal |
EPDM (FPM optional) |
External surface |
Satin and sand blasting |
Internal surface |
Bright light (polished), Ra < 0.8um |
